DASH Tablet PC
- on the go!

Tablet PC

Hand strap

GPS module, or
Barcode imager, or
Magnetic stripe reader



The DASH is a robust Tablet PC, designed to provide mobility in many vertical applications. It is available in 7" and 10.1" display sizes. The DASH is sealed against spill and dust, and is sunlight readable for outdoor applications. With Windows 7 preloaded, application developers will take less time to migrate their existing applications, or develop a new application. As a result, the DASH allows a quicker "go-to-market" product release, and a larger return on investment.

The DASH is slim and weighs less than 2.65 lbs. With a variety of integrated peripherals, such as magnetic stripe reader, barcode imager, and GPS, the DASH allows mobile professionals to achieve a higher productivity.

DASH Features:

  • Slim and light, only 2.65 lbs (1.7 kgs)
  • Sealed againts spill and dust
  • Outdoor viewable
  • Certified to MIL-STD-810G and IP54
  • RFID reader built-in (NFC ready)
  • WiFi 802.11 b/g/n
  • Bluetooth 2.1
  • Runs Microsoft Windows 7 for quicker go-to-market
  • Integrated magnetic stripe reader option
  • Integrated barcode imager (1D and 2D) option



DASH Data Sheet

Model DASH
Display Size 10.1-inch LED Backlight Screen with 5-wire Resistive touch
Display Resolution 1366(W) x 768(H) WXGA
Outdoor Viewable Optional
CPU Intel® Oak Trail™ Atom 1.5
Memory 2GB
Storage 32GB SSD
Operating System Windows 7 Embedded
Communication WiFi 802.11 b/g/n and Bluetooth 2.1
RFID (NFC) 13.56MHz ±7KHz, ISO/IEC 14443A/B, 15693, Mifare and NFC ready
Webcam Front: 1.3 Mega pixel, Audio input
Back: 2 Mega-pixel, LED auxiliary light
Audio 2 x Speakers (internal)
Sensor Light sensor
USB 2.0 Type A 2
Audio Ports 1 x Microphone, 1 x Headphone
Docking Connector 1
Control Buttons Power, Lock, WiFi
Navigation Buttons 4+ Way with integrated Enter button
Function Buttons 5 (programmable)
Barcode Trigger 2 buttons (programmable)
LEDs Power, Storage, WiFi
Dimensions (W x H x D) 10.95 x 8.11 x 1.05 inches (277.8 x 206 x 26.5 mm )
Weight 2.65 lbs (1.2 kgs)
Certifications CE, FCC, UL, VCCI, CCC; CE/FCC SAR
Water/Dust Resistance IP54 equivalent
Drop 4-foot drop (MIL-STD-810G Method 516.6 Procedure IV)
Mechanical Shock Operating: 40g, 12ms, Terminal Sawtooth
Non-Operating: 40g, 12ms, Terminal Sawtooth
Temperature Operating Temperature: 32 ° to 104° F (0° to 40° C)
Storage Temperature: -4° to 140° F (-20° to 60° C)
Humidity 5-90% without condensation
Battery Internal Smart Lithium Polymer Battery, 3800mAH
Docking/Charging Station Optional. Ports: Ethernet, 4 x USB, VGA, HDMI
Power Adapter AC 100V - 240V, 50 - 60Hz, Input: 19VDC @ 3.42A, 65W
Accessories Docking/Charging station
External battery
GPS module
Magnetic stripe reader
Barcode imager (1D and 2D)
Specifications subject to change.

Part Numbers

Part No.
TA-1J21GR-11 10.1" Tablet, Windows 7 Embedded.
TA-DT01 Docking/Charging station
TA-EB101 External battery
TA-GP01 GPS module (external), 50 channels
TA-GT01 GPS/GPRS tracker module (external)
TA-3G01 3G module (external)
TA-MR01 Magnetic stripe reader
TA-BS01 Barcode imager (1D, 2D)
